Features:
- High Performance
- High Reliability
- Low Insertion Loss
- High Isolation
Applications:
- Radar Systems
- Communication Systems
- Receiving Systems
Electrical Specification:
| Numbers of | Frequency Range | VSWR | Insertion Loss | Isolation | Impedance |
| Positions | (GHz) | (max.) | (max)dB | (min)dB | (Ω) |
| 7-8 | DC-6 | 1.30 | 0.3 | 80 | 50 |
| 6-12.4 | 1.40 | 0.4 | 70 | ||
| 12.4-18 | 1.50 | 0.5 | 60 |
| Parameter | Min. | Typ. | Max | Units | |
TTL input | High Level | 2.2 to 5.5V(TTL Option) | Vdc | ||
| Low Level | 0 to 0.8V(TTL Option) | ||||
| Switching time(max) | 20 | ms | |||
| Connector | SMA-Female | ||||
| Temperature Range | -25 to +65 | 0C | |||
| Operation Life (cycles) | 1,000,000(Standard) | ||||
| Vibration (operating) | 10G RMS, 20-2000Hz | ||||
| Mechanical Shock (non-operating) | 50G, 1/2Sine, 11msec | ||||
| Weight(approx.) | 285 g | ||||
Package and Shipment Details:
1) Neutral Master Carton Package;
2) Customized Package;
Product Equipment Line:
Quality Controls:
With more than 10 years experience, we produce A-Grade voltage stabilizer/regulator and can offer OEM & ODM service.
All our products have CE certificate and some have obtained patent.
About us
Clients
FAQ(Frequent Asked Qestions)
Q: What RF switch configurations are available?
A: Below are our popular configurations for your reference, besides, we accept customization.
Electro-mechanical switches: 1P2T (single-pole, double-throw); 1P3T; 1P4T; 1P6T; 1P8T; 1P12T
Solid-state switches: 1P1T; 1P2T; 1P3T; 1P4T; 1P6T; 1P8T; 1P10T; 1P12T; 1P16T
Q: What control options are available?
A: Depending on model, EM RF switches offer TTL logic-level control, or +12, +15 or +28 V DC control. Solid-state switches use TTL logic levels, and one model has a USB interface.
Q: Are the RF switch attenuators bi-directional?
A: All of XINPOMING's RF switches are bi-directional unless noted differently on the specification sheet.
Q: I need a custom RF switch designed. How much are your typical NREs (non-recurring engineering charges)?
A: XINPOMING does not charge NREs. Please send your custom requirement to us for details communication.
Q: Are your 18GHz electro-mechanical switches available with indicators or as latching?
A: Typical options: latching, self-terminating, indicators, TTL, RoHS and non-RoHS.
You're welcomed to contact us for any questions.
