Basic Info.
Model NO.
DQ001-001
3m
9448A, 9495lse
Enbossing
Yes
Adhesive
3m
Thickness
0.3mm
Transport Package
Carton Box
Specification
FPC the biggest 250mm*1200mm
Trademark
DONGQI
Origin
China Guangdong
Production Capacity
1000000 Pieces/Year
Product Description
products description | Circuit level | 35V (DC), 100mA, 1W |
| Contact resistance | 10 Ω~ 500 Ω (varies according to the length and material of outgoing |
| Insulation impedance | 100M Ω 100V |
| Dielectric withstand voltage | no breakdown or flashover after 250V RMS (50-60Hz 1min) test |
| Contact jitter time | ≤5ms |
| Service life | plane type ≥5 million times |
| Touch type | ≥1 million times |
| Operating pressure | plane type 57~ 284g (2 ~ 10oz) |
| Tactile type | 170-397g (6-14oz) |
| Switch stroke | plane type 0.1~ 0.5mm |
Supply Ability
Supply Ability 100000 Piece/Pieces per Month
Packaging & delivery
Packaging Details
1) Wrap in air bubble film
2) Put into foam box
3) Packed with extra carton box, which make sure the goods safety in transportation.
4) We accepted Customized package.
Lead time:
| Quantity(pieces) | 1 - 1000 | 1001 - 10000 | 10001 - 100000 | >100000 |
| Lead time (days) | 7 | 10 | 15 | To be negotiated |
Q1:Are you a manufacturer or trading agent?
A:We are a experienced manufacturer and we also have a professional overseas sales team to serve our customers all over the world.
Q2:Can you offer samples?
A:(1)Stock Samples: If you paid the freight cost, we can provide free samples for you.
(2)Customized Samples: We will offer you 5 pcs free samples after we receive the set up cost.
Q3:How to control quality?
A:(1)We process the products strictly based on the raw material list.
(2)Our many engineer own many years experience and are very responsible.
(3)Warranty period is one year. If you find some products is bad, you can tell us, we will give you solutions.
Q4:Is the prototype necessary?
A:Yes.Most of the items are customized orders,so the prototype will be sent to customer for approval.
Q5:How to make an order?
A:Please tell us your material,artwork design,logic circuit principle chart,size,surface,usage etc. And better send us the design drawing or samples together with other detailed datas, then we'll customize the membrane switch upon your requests.
