Basic Info.
Product Description
Technical Parameters.
In order to give you the best price, please kindly specify your requirements as clearly as possible.
OEM and ODM is welcome, we have professional and experienced engineer team for you.
Features:
- High Performance
- High Reliability
- Low Insertion Loss
- High Isolation
Applications:
- Radar Systems
- Communication Systems
- Receiving Systems
Part Number Selection:
Electrical Specification:
| Connector | Frequency Range | VSWR | Insertion Loss | Isolation | Impedance |
| (GHz) | (max.) | (max)dB | (min)dB | (Ω) | |
| SMA Female | DC-8 | 1.60 | 1.50 | 65 | 50 |
| Parameter | Min. | Typ. | Max | Units | |
| Power Supply | AC110-240/50W | / | |||
| Switching time(max) | 100 | ms | |||
| Connector | SMA-Female | ||||
| Temperature Range | -25 to +65 | 0C | |||
| Operation Life (cycles) | 1,000,000(Standard) | ||||
| Weight(approx.) | / | ||||
Package and Shipment Details:
1) Neutral Master Carton Package;
2) Customized Package;
Product Equipment Line:
Quality Controls:
With more than 10 years experience, we produce A-Grade voltage stabilizer/regulator and can offer OEM & ODM service.
All our products have CE certificate and some have obtained patent.
About us
FAQ(Frequent Asked Qestions)
Q: What RF switch configurations are available?
A: Below are our popular configurations for your reference, besides, we accept customization.
Electro-mechanical switches: 1P2T (single-pole, double-throw); 1P3T; 1P4T; 1P6T; 1P8T; 1P12T
Solid-state switches: 1P1T; 1P2T; 1P3T; 1P4T; 1P6T; 1P8T; 1P10T; 1P12T; 1P16T
Q: What control options are available?
A: Depending on model, EM RF switches offer TTL logic-level control, or +12, +15 or +28 V DC control. Solid-state switches use TTL logic levels, and one model has a USB interface.
Q: Are the RF switch attenuators bi-directional?
A: All of XINPOMING's RF switches are bi-directional unless noted differently on the specification sheet.
Q: I need a custom RF switch designed. How much are your typical NREs (non-recurring engineering charges)?
A: XINPOMING does not charge NREs. Please send your custom requirement to us for details communication.
Q: Are your 18GHz electro-mechanical switches available with indicators or as latching?
A: Typical options: latching, self-terminating, indicators, TTL, RoHS and non-RoHS.
You're welcomed to contact us for any questions.
