Basic Info.
Model NO.
PFNC171
Name
Good Quality Bimetal Thermostat for Refrigerator
MOQ
1000PCS
Application
Refrigerator
Transport Package
Normal Packing or Per Customer′s Requirement
Specification
CE
Trademark
SANHE
Origin
China
HS Code
85168000
Production Capacity
500, 000PCS/Year
Packaging & Delivery
Package Size
8.00cm * 8.00cm * 5.00cm
Package Gross Weight
0.500kg
Product Description
| A serise | ||||||||
| Model | Operating Temperature°C | Capillary Length (mm) | Contact Style | |||||
| Cold | Normal | Warm | ||||||
| On | Off | On | Off | On | Off | |||
| A10-6580-057 | 4.5 | 1.5 | -- | -- | 16 | 13.5 | 520 | S.P.S.T |
| A10-7006-057 | 4 | 1 | -- | -- | 15 | 12 | 520 | S.P.S.T |
| A22-1056-057 | 19 | 16 | -- | -- | 33 | 30 | 375 | S.P.D.T |
| A30-2266-057 | 21 | 17.5 | -- | -- | 33.5 | 30.5 | 610 | S.P.S.T |
| WA-30 | 18 | 15 | -- | -- | 30 | 27 | 520 | S.P.S.T |
| WL-1.5A | -- | -- | 4 | 0 | -- | -- | 420 | S.P.S.T |
| WL-1A-WX | -- | -- | -- | 1 | -- | -- | 460 | S.P.S.T |
| WP-1A | 19 | 17 | -- | -- | 32 | 30 | 520 | S.P.D.T |
| F serise | ||||||||
| GTLH0138 | 4 | 0 | 4 | 20 | 4 | 40 | 965 | S.P.S.T. |
| GTLH0204 | 6 | 50 | -- | -- | 6 | 320 | 875 | S.P.S.T. |
| GTLH0398 | 8.5 | 0 | -- | -- | 8.5 | 250 | 200 | S.P.S.T. |
| WDRF0T85S | 5 | 0 | -- | -- | 5 | 85 | 875 | S.P.D.T. |
| WPR-250F | 7 | 50 | -- | -- | 7 | 250 | 875 | S.P.S.T. |
| WPR-300F | 7 | 0 | -- | -- | 7 | 300 | 1000 | S.P.S.T. |
| WSRF0T150S | 7 | 0 | -- | -- | 7 | 150 | 1000 | S.P.S.T. |
| WSRF25T75Sr | 5.5 | 25 | -- | -- | 5.5 | 75 | 800 | S.P.S.T. |
| WSRF40T200S | 8 | 40 | -- | -- | 8 | 200 | 1000 | S.P.S.T. |
| S serise | ||||||||
| AWTB 124GS | -25 | -30 | -- | -- | -10 | -14 | 650 | S.P.S.T |
| YMTB 604G | 18 | 15 | -- | -- | 33 | 30 | 460 | S.P.S.T |
| WK30 606S | 22 | 19 | -- | -- | 34.5 | 32 | 500 | S.P.S.T |
| WPF-6 | 6 | -0.5 | -- | -- | 20 | 14 | 570 | S.P.S.T |
| WPF-5 | -2 | -5 | -- | -- | 12 | 7 | 1350 | S.P.S.T |
| WR-30 | 15 | 18 | -- | -- | 27 | 30 | 240 | S.P.D.T |
| WR-50 | 18 | 15 | -- | -- | 50 | 46.5 | 200 | S.P.D.T |
| WR-50-S | 15 | 18 | -- | -- | 46.5 | 50 | 200 | S.P.D.T |
| WR-45 | 15 | 18 | -- | -- | 41.5 | 45 | 200 | S.P.D.T |
| WPF-22 | -16 | -22 | -- | -- | -5 | -10 | 800 | S.P.S.T |
| PFA606S | 21 | 18.5 | -- | -- | 34 | -- | 500 | S.P.S.T |
| WP-5 | -- | -- | 5 | 2 | -- | -- | 1200 | S.P.D.T |
| PFNC171 | -25 | -30 | -16 | -20 | -11.5 | -15.5 | 240 | S.P.S.T |
| E serise | ||||||||
| Model | Type | Operating Temperature°C | Capillary Length (mm) | Capillary Length (mm) | Contact Style | |||
| Cold | Warm | |||||||
| On | Off | On | Off | |||||
| 55.13019.314 | -- | 8 | -50 | 8 | 270 | 1540 | -- | -- |
| 55.13059.220 | -- | 5 | -30 | 5 | 85 | 980 | -- | -- |
| WSRE0T50Sx | -- | 5 | 0 | 5 | 50 | 1000 | -- | -- |
| WSRE150T500S | -- | 12 | -150 | 12 | 500 | 1000 | -- | -- |
| WSRE30T90Sr | -- | 5 | -30 | 5 | 90 | 600 | -- | -- |
| WSRE50T110S | -- | 5 | -50 | 5 | 110 | 1000 | -- | -- |
| WSRE50T250S | -- | 8 | -50 | 8 | 250 | 1000 | -- | -- |
| WSRE50T300S | -- | 8 | -50 | 8 | 300 | 1000 | -- | -- |
| WSRE50T300Sx | -- | 8 | -50 | 8 | 300 | 1000 | -- | -- |
| WSRE30T90Sx | -- | 5 | -30 | 5 | 90 | 1000 | -- | -- |
| K serise | ||||||||
| K50-P1110(VC1) | -- | -14.5 | -23 | 2 | -- | OFF | 1200 | S.P.S.T |
| K50-P1174(VA2) | -- | -14 | -17 | 5 | 3 | OFF | 2500 | S.P.S.T |
| K54-P1102(VS5) | -- | -20 | -26 | -10 | -16 | SIGNAL-15/-5 | 2000 | D.P.D.T |
| K55-L5010(VW8) | -- | 18.5 | 16 | 35 | 33 | -- | 1200 | S.P.S.T |
| K59-L1102(VT9) | -- | 3.5 | -22 | 3.5 | -12 | OFF | 1200 | S.P.S.T |
| K50 P11 25 | -- | -9.5 | -18 | 8.5 | -- | OFF | 1200 | S.P.S.T |
| K50 P11 26 | -- | -18 | -24.5 | -9.5 | -- | OFF | 1200 | S.P.S.T |
| K50 P11 27 | -- | 5 | 1.5 | 12.5 | -- | OFF | 1200 | S.P.S.T |
| K60 P11 29 | -- | -15 | -24 | -2.5 | -8.5 | DEFROST 6 | 950 | S.P.S.T |
| WDF-19K | -- | 3.5 | -19 | 3.5 | -9 | OFF | 800 | S.P.S.T |
| GE Style Thermostat | ||||||||
| 3ART5C 101 | -- | -23 | -32 | -15 | -22 | OFF | 1015 | S.P.S.T |
| 3ART5KT41 | GC501 | -- | -27 | 3.5 | -- | OFF | 1100 | S.P.S.T |
| 3ART5 VC154 | -- | -1.5 | -15 | 6.5 | -3.5 | OFF | 420 | S.P.S.T |
| 3ART5 VC171 | -- | -6 | -16 | 3 | -4 | OFF | 420 | S.P.S.T |
| 3ART5 VN8 | -- | -4 | -11 | 2 | -3.5 | OFF | 680 | S.P.S.T |
| 3ART5 VW1 4 | ER2198202 | -2 | -13.5 | 5 | -3.5 | OFF | 1000 | S.P.S.T |
| 3ART5C 22 5 | 200D5822P001 | -3.5 | -13.5 | 4 | -3.5 | OFF | 650 | S.P.S.T |
| 3ART5 VC158 | 450 226-08 | 2 | -2.7 | 8.5 | 4.7 | OFF | 850 | S.P.S.T |
| YX Style Thermostat | ||||||||
| 711 | TF-TRC-SB(-35/+35) | -30 | DIFF:3 | 30 | DIFF:3 | -- | 1450 | S.P.D.T |
| F2000 | TF-TRC | -30 | DIFF:3 | 30 | DIFF:3 | -- | 1450 | S.P.D.T |
| A2000 | TF-TRA | -30 | DIFF:3 | 30 | DIFF:3 | -- | 15 | S.P.D.T |
