Basic Info.
Model NO.
EPI Series
Rated Making & Breaking Capacity
3le,1.05 Ue
Rated Insulation Voltage Ui
690V
Rated Impulse Withstand Voltage Uimp
6kv
Electrical Endurance
1500
Mechanical Endurance
10000
Type of Terminal
Lug Type and Pin Type
Terminal Capacity
Cables up to 50 Square Millimeter
Altitude (Meters)
Max.2000
Protection Degree
IP20
Transport Package
Carton
Specification
small
Trademark
Eleco
Origin
Zhejiang, China
Production Capacity
10000PCS/Month
Product Description
4P Lug type and Pin type Isolating Switch Series
Technical data
Features
1.Current capacity is enhanced and electric drive compensation is fully applied
2.Reliable operation thanks to special designed operating mechanism
3.Safe operation is ensured
Endurance(operations)
About us
ELECO Electric is one of the most specialized manufacturers and exporters for modular electric terminal devices for household and similar installations in China. The wide range products under manufacturing covers Miniature Circuit Breaker(MCB),Residual Current Circuit Breaker(RCCB), Residual Current Circuit Breakers with Overcurrent Protection(RCBO),Switch -disconnector,Distribution Box, Moulded case circuit breaker(MCCB), air circuit breake (ACB), AC Contactor,Magnetic Dtarter, Motor Protection Circuit Breaker, Thermal Relay and K.W.H meter etc.The company takes the reputation as one of the largest manuafacturer of electro-magnetic type RCCB and RCBO. OEM or ODM projects are fully accepted, and currently the company is co-operating with numbers of renowned international corporations for such projects.
Experience in manufacturing under customers design, trade, biding project, OEM and competitive cooperation related to the new products & technology. Won approvals of CE, SEMKO, CB, KEMA, FI, CCC and ISO9001 Quality System Certificate etc. Products being popular around the world, such as Europe, America, Southeast Asia, Middle East, Africa, etc.
Technical data
| Standard | EN/IEC60947-3 | ||||
| Number of poles | 1P,2P,3P,4P | ||||
| Rated currents | 16,20,25,32,40,50,63,80,100,125A | ||||
| Rated voltage | 1 pole 240VAC 50/60Hz | ||||
| Utilization category | AC-22A | ||||
| Rated short-circuit making capacity lcm | 20le | ||||
| Rated making & breaking capacity | 3le,1.05Ue, cosΦ=0.65 | ||||
| Rated insulation voltage Ui | 690V | ||||
| Rated impulse withstand voltage Uimp | 6kv | ||||
| Electrical endurance | 1500 | ||||
| Mechanical endurance | 10000 | ||||
| Type of terminal | Lug type and Pin type | ||||
| Terminal capacity | Cables up to 50 square millimeter | ||||
| Ambient termperature (ºC) | -5 ~+35, Max.95% humidity | ||||
| Storage temperature(ºC) | -40~+75 | ||||
| Altitude (meters) | Max.2000 | ||||
| Protection degree | IP20 | ||||
| Installation | Mounting on 35mm DIN rail | ||||
| Width | 17.8mm per pole | ||||
Features
1.Current capacity is enhanced and electric drive compensation is fully applied
2.Reliable operation thanks to special designed operating mechanism
3.Safe operation is ensured
Endurance(operations)
| Category | Operations | Operation Frequency | Rated Current |
| Electrical Endurance | 1500 | 120/h | 16~125A |
| Mechanical Endurance | 10000 | 120/h | 16~125A |
